SD4245

Download SD4245 Datasheet
Overview & Features Specification Stock & Documentation

Overview & Features

Details coming soon

Specification

Product Specifications
Resolution 14-bit Speed (Msps) 125
Number of Channels 2 SFDR (dBc)@70.2MHz 88.28
SNR (dBFS)@70.2MHz 75.19
Drop-in Replacement Replacement Part # Plural Price ($) Replacement Part Price Package
Yes ADS4245 $26.52 $37.88 64 pins (9x9 package)

Stock, EVKs & Documentation

Part NumberDistributorStockPricingLinks
SD4245-R14-ET-A-QC9-TADigiKey
50 units
1+: $122.46
SD4245-R14-A-QC9-TADigiKey
50 units
1+: $56.11
Last updated: July 17, 2026 8:43 pm

Evaluation Kits for SD4245

Kit Name Resolution Speed Channels Description Availability User Guide EVK Download
SDE1119-C
Mouser Electronics Stock: 5 USD 234.04 View
Mouser Electronics Stock: 5 USD 234.04 View
DigiKey Stock: 6 USD 226.12 View
View on TrustedParts →
14 20-250 1 or 2 14 Bit 20-250MSPS Single and Dual Channel Analog to Digital Converter (ADC) Evaluation Board - CMOS Interface with 64 pin package ADC Now
SDE1119-L
DigiKey Stock: 6 USD 226.12 View
Mouser Electronics Stock: 5 USD 234.04 View
Mouser Electronics Stock: 5 USD 234.04 View
View on TrustedParts →
14 20-250 1 or 2 14 Bit 20-250MSPS Single and Dual Channel Analog to Digital Converter (ADC) Evaluation Board - LVDS Interface with 64 pin package ADC Now
SDE9649-C
Mouser Electronics Stock: 5 USD 234.04 View
Mouser Electronics Stock: 5 USD 234.04 View
DigiKey Stock: 6 USD 226.12 View
View on TrustedParts →
14 20-250 1 14 Bit 20-250MSPS Single and Dual Channel Analog to Digital Converter (ADC) Evaluation Board - CMOS Interface with 32pin package ADC Now
Altium EVK PCB design file
