-55°C
+125°C
Guaranteed Operational Performance
EXTENDED TEMPERATURE RANGE ADCS
Over 50 devices from 5 to 250 Msps available
Aerospace & Defense | Industrial
Software Defined Radio | Medical
10-bit, 12-bit, 14-bit & 16-bit ADCs
| Part/Data Sheet | Resolution | Speed (Msps) | # of Channels | SFDR (dBc) @70.2MHz | SNR (dBFS) @70.2MHz | Extended-Temp (Y/N) | Feature Rich (Y/N) | Drop-in Replacement | Replacement Part # | Package | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 14-bit | 80 | 2 | 87 | 73 | Y | Yes | LTC2143-14 | 64 pins (9x9 package) | Inquire | ||
| 12-bit | 105 | 2 | 86 | 70.1 | Y | Yes | LTC2144-12 | 64 pins (9x9 package) | Inquire | ||
| 14-bit | 105 | 2 | 85 | 72.4 | Y | Yes | LTC2144-14 | 64 pins (9x9 package) | Inquire | ||
| 12-bit | 125 | 2 | 84 | 70.3 | Y | Yes | LTC2145-12 | 64 pins (9x9 package) | Inquire | ||
| 14-bit | 125 | 2 | 84 | 72.4 | Y | Yes | LTC2145-14 | 64 pins (9x9 package) | Inquire | ||
| 12-bit | 125 | 2 | 84 | 70.3 | Y | Yes | ADS4225 | 64 pins (9x9 package) | Inquire | ||
| 12-bit | 160 | 2 | 83 | 70.3 | Y | Yes | ADS4226 | 64 pins (9x9 package) | Inquire | ||
| 14-bit | 65 | 2 | 90 | 73 | Y | Yes | ADS4242 | 64 pins (9x9 package) | Inquire | ||
| 14-bit | 125 | 2 | 84.4 | 72.4 | Y | Yes | ADS4245 | 64 pins (9x9 package) | Inquire | ||
| 14-bit | 160 | 2 | 82 | 72.5 | Y | Yes | ADS4246 | 64 pins (9x9 package) | Inquire | ||
| 12-bit | 20 | 2 | 89 | 70.6 | Y | Yes | AD9231-20 | 64 pins (9x9 package) | Inquire | ||
| 12-bit | 40 | 2 | 83 | 70.6 | Y | Yes | AD9231-40 | 64 pins (9x9 package) | Inquire | ||
| 12-bit | 65 | 2 | 88 | 70.5 | Y | Yes | AD9231-65 | 64 pins (9x9 package) | Inquire | ||
| 12-bit | 80 | 2 | 87 | 70.6 | Y | Yes | AD9231-80 | 64 pins (9x9 package) | Inquire | ||
| 14-bit | 20 | 2 | 91 | 73.1 | Y | Yes | AD9251-20 | 64 pins (9x9 package) | Inquire | ||
| 14-bit | 40 | 2 | 84 | 73 | Y | Yes | AD9251-40 | 64 pins (9x9 package) | Inquire | ||
| 14-bit | 65 | 2 | 90 | 73 | Y | Yes | AD9251-65 | 64 pins (9x9 package) | Inquire | ||
| 14-bit | 80 | 2 | 87 | 73 | Y | Yes | AD9251-80 | 64 pins (9x9 package) | Inquire | ||
| 14-bit | 105 | 2 | 85 | 72.4 | Y | Yes | AD9258-105 | 64 pins (9x9 package) | Inquire | ||
| 14-bit | 125 | 2 | 84 | 72.4 | Y | Yes | AD9258-125 | 64 pins (9x9 package) | Inquire | ||
| 14-bit | 80 | 2 | 87 | 73 | Y | Yes | AD9258-80 | 64 pins (9x9 package) | Inquire | ||
| 12-bit | 170 | 2 | 81.6 | 70 | Y | Yes | AD9613-170 | 64 pins (9x9 package) | Inquire | ||
| 12-bit | 210 | 2 | 79.3 | 69.7 | Y | Yes | AD9613-210 | 64 pins (9x9 package) | Inquire | ||
| 12-bit | 105 | 2 | 86 | 70.1 | Y | Yes | AD9628-105 | 64 pins (9x9 package) | Inquire | ||
| 12-bit | 125 | 2 | 84.8 | 70.3 | Y | Yes | AD9628-125 | 64 pins (9x9 package) | Inquire | ||
| 12-bit | 20 | 1 | 89 | 70.6 | Y | Yes | AD9629-20 | 32 pins (5x5 package) | Inquire | ||
| 12-bit | 65 | 1 | 88 | 70.5 | Y | Yes | AD9629-65 | 32 pins (5x5 package) | Inquire | ||
| 12-bit | 80 | 1 | 87 | 70.6 | Y | Yes | AD9629-80 | 32 pins (5x5 package) | Inquire | ||
| 14-bit | 170 | 2 | 82.5 | 72.2 | Y | Yes | AD9643-170 | 64 pins (9x9 package) | Inquire | ||
| 14-bit | 105 | 2 | 85 | 72.4 | Y | Yes | AD9648-105 | 64 pins (9x9 package) | Inquire | ||
| 14-bit | 125 | 2 | 84 | 72.4 | Y | Yes | AD9648-125 | 64 pins (9x9 package) | Inquire | ||
| 14-bit | 20 | 1 | 91 | 73.1 | Y | Yes | AD9649-20 | 32 pins (5x5 package) | Inquire | ||
| 14-bit | 40 | 1 | 84 | 73 | Y | Yes | AD9649-40 | 32 pins (5x5 package) | Inquire | ||
| 14-bit | 65 | 1 | 90 | 73 | Y | Yes | AD9649-65 | 32 pins (5x5 package) | Inquire | ||
| 14-bit | 80 | 1 | 87 | 73 | Y | Yes | AD9649-80 | 32 pins (5x5 package) | Inquire |
Choose ResolutionPlatform™
10-bit ADC
20Msps to 250Msps
12-bit ADC
20Msps to 250Msps
14-bit ADC
20Msps to 250Msps
16-bit ADC
20Msps to 125Msps
